SGA40WJ Cheese packing machine under normal temperature

SGA40WJ Cheese packing machine under normal temperature

SGA40WJ Cheese packing machine under normal temperature is designed for Dairy products under normal temperature. The machine with sterilizition system itself , after packaging , the final products can be stored under normal temperature .it is the single dose processd cheese after melting filled into formed shaped film cantainer, after hot forming , insert stick and then filling and sealing , after colding ,to be cutted into single finish products.

SGA40WJ Cheese packing machine a whole cooperate body ,whih is running under a clearning enviroment whih is consisted by air stelirizition layer and steliriziong tank . The whole process include foil spreading ,transmission system,heating system , forming ,end sealing ,filling ,colding and cutting to finish the final product.

Product Details

一、Character

1.Easy to operate, safety and reduce the cost of packing film.

2.Integrated design, simple structure, shorter time drawing, higher working capacity.

3.Good quality, run stable, long life.

4.Packing film can be simplex film also can be compouded film.

5.Machines base is very firm.

6.Higher using rate of packing film which can be more than 95%, some is more than 99%.


Parameter:



Foil

PVC/PE、PET/PE、PVC/PS

Foil specification

(0.3~0.4)*250max(mm)

Foil width

120-240mm

Dose

 1-120 ml/pcs

Double sides forming depth

≤25mm

Single side forming depth

≤12.5mm

Capacity

350-400pcs/min

Air consumption

0.6Mpa, 110L/min

Filling accuracy

≤2%

Cold water consumption

0.15-0.2Mpa,  280L/H

Power

60 kW

Voltage

380V 50Hz

Dimension

11500*1280*2900mm

Weight

8000kg
