HDS120 Automatic Cartoning Packing Machine

HDS120 Automatic Cartoning Packing Machine has the function of putting the blister products or other products and leaflet into one box synchronously. The machine having the ability of folding leaflet, coding batch number, putting blister package or pillow package into box and stacking.It has high efficiency and good quality. The whole working process is controlled by PLC, photoelectric monitor, transducer, and wording display. If there is any problem during the working process, the machine can stop automatically and display reasons so that the problem can be solved in time.

Product Details

Features：

1、This machine is multifunction carton packing machine , products specification is wide scope , leaflet can be folded 4 times . Structure is easy operation and adjustment ,save labor cost .

2、Machine with superior inspection sensor to confirm the machine will automatic alarm or stop running if there are absent of leaflet , packing products and carton .

3、The feeder can be OEM designed according to the different packing products .

4、The machine is controlled by PLC and HMI , with batch No.embossing process and also have the detection system , it will detect the carton which without packing products or without leaflet .

5、Carton input system is interupt working , with overload protect function , to assure the packing products with leaflet into carton safely .

6、The full machine with high speed and lower noise .

Parameters：

Leaflet size	(100-250)x(120-160)mm
Carton quality	250~350g/㎡
Carton size	(70-160)x(30-88)x(12-60)mm
Capacity（Leaflet）	≤100pages/min
Capacity（Carton）	≤90cartons/min
Air Consumption	0.2-0.3m3/min　Pressure 0.4~0.6MPa
Noise	Max 70dB
Power	2 kW
Voltage	380V 50Hz
Dimension	1300×970×1600mm
