CM200/HD260 Automatic high speed carton packing machine

CM200/HD260 Automatic high speed carton packing machine

CM200/HD260 Automatic high speed carton packing machine is the horizontal type machine used to pack pharmaceutical blisters ,vials, soft tubes and so on.he function of the machine is open the carton, fold leaflet, fill the product, stamp the batch No. insert the carton. transfer the finish box and so on . which make the carton transferring and product filling matched and cooperated , which improve the produce capacity and higher automatic ability .

Product Details

 Features:

  1. The machine is continue working system , so it is high speed runing with high capacity .

  2. The transportation of the machine use synchronous belt , lower noise and clean no oil .

  3. The products is pushed into carton within several steps , not one time pushing .To confirm the products is good in pushing process .

  4. PLC and HIM control system .

  5. All the machine can inspection the final products well , if there is no products or no leaflet , the final carton will be detected automatically .

  6. The machine with overal load protect system , if there are any suddenly situation the machine will stop automatically .





Parameter:

Item

CM200

HD260

Leaflet quality

 60~70g/㎡

 60~70g/㎡

Leaflet specification

   Max: 200x200mm Min: 130x90mm

   Max: 200x200mm Min: 130x90mm

Leaflet thick deviation

±2μm

±2μm

Carton storage environment

 Temperature 25℃±2℃;Relative humidity≤60%

 Temperature 25℃±2℃;Relative humidity≤60%

Carton quality

 300~350g/㎡

 300~350g/㎡

Carton thick deviation

  Max: 150x95x60mm Min: 80x35x18mm

  Max: 170×115×60mm Min: 80×40×18mm

Temperature

 ±5μm

 ±5μm

Leaflet capacity

 Max 200cartons/min

 Max 260cartons/min

Carton capacity

0.06-0.09m³/min pressure 0.6~0.9MPa

0.06-0.09m³/min pressure 0.6~0.9MPa

Air consumption

 Max 75dB

 Max 70dB

Noise

 1.5 kW

3 kW

Power

 380V 50Hz

 380V 50Hz

Voltage

4800x1620 x1600mm

6000×1600×1500mm

Dimension

 2500kg

 3500kg
